Original EPISTAR LEDsAluminum Housing ADC12 Die-cast LiFud driver.High CRI >80Ra

Product Categories
Power Real CO.,Limited
Contact Now

Original EPISTAR LEDsAluminum Housing ADC12 Die-cast LiFud driver.High CRI >80Ra

  • 1
  • 2
  • 3

Brand Name : Power-Real

Model Number : PR-SF1103

Certification : CE RoHS

Place of Origin : China

MOQ : 50Pcs

Payment Terms : L/C, D/A, D/P, T/T, Western Union

Material : Aluminum

Contact Now

Features :
DIM LED Downlight

1.LED chips : Original EPISTAR LEDs

2.LED Driver : LiFud driver

3.Aluminum Housing : ADC12 Die-cast

4.Dimmable option :triac , 0-10V , DALI

5.200-240VAC , 100-270VAC

6.LM-80 approved , 90-100LM/W

7.Color Temperature : 2700K ,3000K , 4000K , 5000K , 5700K , 6500K

8.High CRI >80Ra

9.5 years warranty

10.UL/TUV/SAA/CB/CE Certificate

Specification :


Model		 LED Lumen Power Voltage Beam angle Size (mm) Cuthole (mm)
PR-SF1103-9 18 LEDs SANAN 0.5W 2835 630 lm 9 W 220-240V
100-277V		 120° Ø108*H52 Ø95(3.74")
PR-SF1104-15 30 LEDs SANAN 0.5W 2835 1050 lm 15 W 220-240V
100-277V		 120° Ø142*H65 Ø125(4.92")
PR-SF1105-20 40 LEDs SANAN 0.5W 2835 1600 lm 20 W 220-240V
100-277V		 120° Ø158*H75 Ø140(5.51")
PR-SF1106-30 60 LEDs SANAN 0.5W 2835 2400 lm 30 W 220-240V
100-277V		 120° Ø185*H88 Ø170(6.69")
PR-SF1108-40 80 LEDs SANAN 0.5W 2835 3200 lm 40 W 220-240V
100-277V		 120° Ø226*H108 Ø210(8.27")
PR-SF1110-60 120 LEDs SANAN 0.5W 2835 4800 lm 60 W 220-240V
100-277V		 120° Ø282*H130 Ø265(10.43")



Original EPISTAR LEDsAluminum Housing ADC12 Die-cast LiFud driver.High CRI >80RaOriginal EPISTAR LEDsAluminum Housing ADC12 Die-cast LiFud driver.High CRI >80RaOriginal EPISTAR LEDsAluminum Housing ADC12 Die-cast LiFud driver.High CRI >80RaOriginal EPISTAR LEDsAluminum Housing ADC12 Die-cast LiFud driver.High CRI >80Ra
